| Place of Origin: | CHINA |
| ブランド名: | IKP |
| 証明: | CE/UL/REACH/ROHS |
| モデル番号: | トロイダルトランス |
| 最小注文数量: | 1000 |
|---|---|
| 価格: | 3.00-20.00 |
| パッケージの詳細: | カートン |
| 受渡し時間: | 10〜15日 |
| 支払条件: | L/C、T/T |
| 供給の能力: | 100,000/週 |
Specifications:
• Power range:100VA to 1000VA
• Input / Output: Customized
• Insulation Class: UL class B, F, H, N (optional)
• Isolation: 4KV (Hi-pot)
• Easy to change diameter and height of the core
• Customized specifications are welcome
|
Rated Power (VA) |
Outside Dimension D*H(mm) |
Weight (kg) |
Temp. Rise (℃) |
Approval |
| 100 | 95*45 | 1.24 | 51 | UL/CE/RoHS/CQC |
| 300 | 125*56 | 2.95 | 53 | UL/CE/RoHS/CQC |
| 500 | 140*65 | 4.20 | 55 | UL/CE/RoHS/CQC |
| 600 | 146*71 | 5.20 | 56 | UL/CE/RoHS/CQC |
| 800 | 170*65 | 6.30 | 57 | UL/CE/RoHS/CQC |
| 1000 | 170*75 | 7.20 | 58 | UL/CE/RoHS/CQC |
◆We can design and manufacture customized part with specific requirement
◆We can design and manufacture customized part with specific requirement◆We can design and manufacture customized part with specific requirement
