| 起源の場所: | 中国 |
| ブランド名: | IKP |
| 証明: | CE/UL/REACH/ROHS |
| モデル番号: | トロイダルトランス |
| 最小注文数量: | 1000 |
|---|---|
| 価格: | 3.00-20.00 |
| パッケージの詳細: | カートン |
| 受渡し時間: | 10〜15日 |
| 支払条件: | L/C、T/T |
| 供給の能力: | 100,000/週 |
Specifications:
• Power range:500VA to 10000VA
• Phase: Single
• Input / Output: Customized
• Insulation Class: UL class B, F, H, N (optional)
• Isolation: 4KV (Hi-pot)
• Easy to change diameter and height of the core
• Customized specifications are welcome
|
Rated Power (VA) |
Outside Dimension D*H(mm) |
Weight (kg) |
Temp. Rise (℃) |
Approval |
| 500 | 145*65 | 5.5 | 52 | UL/CE/RoHS/CQC |
| 1000 | 175*85 | 8.5 | 54 | UL/CE/RoHS/CQC |
| 2000 | 210*90 | 14.7 | 55 | UL/CE/RoHS/CQC |
| 2500 | 210*100 | 16.7 | 56 | UL/CE/RoHS/CQC |
| 3000 | 215*105 | 17.7 | 57 | UL/CE/RoHS/CQC |
| 3500 | 230*115 | 21.8 | 58 | UL/CE/RoHS/CQC |
| 5000 | 290*115 | 30.0 | 59 | UL/CE/RoHS/CQC |
| 7000 | 330*115 | 35.0 | 62 | UL/CE/RoHS/CQC |
| 10000 | 360*115 | 45.0 | 65 | UL/CE/RoHS/CQC |
◆We can design and manufacture customized part with specific requirement
